Details

---

'GEN-X', the next generation in pumps, is a state-of-the-art line of end suction
centrifugal pumps, which hydraulic wet-ends are entirely manufactured from
pressed stainless steel - AISI304 or AISI316.

Conformed to EN733, DIN24255 standards, GEN-X is one of superior quality and
efficiency to meet today's sophisticated application requirements in the building
services and general industry.

GEN-X is designed with two versions - Model GX which motor is close-coupled
to the pump hydraulics, with the impeller mounted on the extended shaft of the
motor. In Model GXF, the standard IEC motor is coupled to the hydraulics via a
stub-shaft and an intermediate adaptor. This facilitate immediate replacement
of the motor should need arises, and allows user an option to use motor of their
choice.

DESIGN FEATURES

STAINLESS STEEL CONSTRUCTION | All wetted parts are made of high quality polished stainless steel, with options
of AISI304 or AISI316, offering not only excellent resistance to corrosion; but smooth water passage hence optimising
performance.

CASING | Designed with centreline discharged, ensuring maximum resistance to misalignment and distortion
from pipe loads. The volute casing is designed as an integral part of the pump body.

'BACK PULLOUT' FEATURE | 'Back pullout' feature allows pump casing to remain connected to pipeline, while
impeller, backplate & motor assembly can removed for service.

IMPELLER | Impeller is of enclosed type, with projection-welded blades.

SHAFT SEAL | Mechanical seals conforming to DIN24960, are fitted as standard. Depending on characteristics of
liquid handled, various sealing material options are available.

MOTOR | Coupled to totally enclosed fan-cooled (TEFC), aluminium-finned frame motor, with IP55 weatherproof
protection rating as standard.
